Patent Drawing in Tokyo.

A patent drawing Tokyo filing depends on is not a translated US sheet. The Japan Patent Office sits in Kasumigaseki, a short walk from the Tokyo District Court that will hear any infringement action arising from the granted right, and it applies its own formal rules — monochrome line work, its own view conventions, and a design practice that diverged sharply from US practice after the 2019 Design Act. Tokyo also concentrates the filers who feel those rules hardest: electronics, precision machinery, pharmaceutical and robotics companies headquartered in Kantō. Getting the sheets right at filing is cheaper than correcting them under a JPO notice of reasons for refusal.

Where a patent drawing Tokyo filing is examined

The Japan Patent Office (JPO) examines every national application from its headquarters in Kasumigaseki, Chiyoda-ku. For an invention patent, drawings are filed where necessary — the statutory application comprises a request, a description, claims, drawings if required, and an abstract. That optionality misleads foreign filers. In practice, almost every mechanical, electronic or device-based Japanese application carries drawings, because the JPO reads the claims against the description and the figures together, and a claim term that the figures do not support attracts a clarity objection.

The formal requirements are stricter than the EPO’s. The JPO requires black-and-white line drawings for patent applications; colour and photographic submissions are not accepted as a matter of form. Sheets are prepared to JIS A4, lettering is black, and the electronic filing format is prescribed. A US sheet that relies on greyscale photographs or colour to carry meaning has to be redrawn before it can be filed in Tokyo, not merely relabelled.

This is the first place a Euro-PCT or Paris-route filing goes wrong. The drawings that satisfied the USPTO under 37 CFR 1.84, or that were accepted by the EPO, are not automatically compliant here, and the translation stage is the wrong moment to discover it.

Utility models: the Tokyo filing where drawings are mandatory

Japan’s utility model system changes the analysis entirely, and it is heavily used by Kantō component and precision-machinery makers. Under Article 5(2) of the Utility Model Act, a utility model application must be accompanied by drawings. Not “where necessary” — always. The reason is structural: a utility model protects a device relating to the shape or structure of an article, or a combination of articles, so the shape is the subject matter and the drawings are the disclosure.

Compounding this, Japanese utility models are registered without substantive examination. There is no examiner to probe an ambiguous figure and no office action in which to clarify it. Whatever the sheets show at filing is what the registered right discloses, and any weakness surfaces later — when the holder requests a Utility Model Technical Opinion before asserting the right, or when a defendant attacks it.

For a Tokyo filer choosing the utility model route for speed, that shifts the drawing budget forward. The sheets are not supporting material; they are the asset. Cross-sections, assembly relationships and dimensional relationships that a patent specification could carry in prose have to be visible on the sheet.

Japanese design drawings after the 2019 Design Act

The revised Design Act, in force 1 April 2020, was the largest change to Japanese design practice in a generation, and it directly expanded what design illustrators are asked to draw. Three categories became registrable that were not before: images — including graphical interfaces not pre-installed on a device and images projected onto surfaces — buildings, and interior designs. Registered Japanese architectural and interior designs now include retail and station buildings.

The revision also extended the term of a design right to 25 years from the filing date, replacing the previous 20 years from registration, and widened the related-design system so that related applications can be filed up to 10 years after the basic design, with related designs registrable against other related designs.

For Tokyo consumer-electronics and retail filers this is a practical drafting question, not an abstract one. An interior design has to be depicted so that the space itself — not merely the furniture in it — is identifiable as a unified design, and an image design has to be shown in a way that separates the protected image from the device displaying it. Those are drawing decisions made at filing.

Partial designs use dash-dotted lines, not US broken lines

Japan has protected partial designs (部分意匠, bubun ishō) since 1999, and the convention differs from the one US practitioners carry in their heads. Under 37 CFR 1.152 a US design application disclaims unclaimed matter by drawing it in broken lines, and the drawing alone does that work.

The JPO requires more. The application must contain a written statement identifying which part is claimed and by what method it has been depicted. The boundary between the claimed portion and the remainder may be shown by a dash-dotted line, or the claimed portion may instead be distinguished by colouring. Because more than one depiction method is permitted, the statement is what makes the drawing unambiguous — and a mixed solid-and-broken-line sheet imported from a US filing, with no statement, is exactly the case the JPO warns is difficult to read at a glance.

Infringement is then assessed against the claimed portion only. A Tokyo partial-design filing converted from a US parent therefore needs both the sheets re-marked and the statement drafted to match them — a step that is routinely missed when a design family is extended into Japan late in the priority year.

Six views are no longer mandatory at the JPO

Japanese design practice was for decades associated with a rigid six-view requirement: front, rear, left side, right side, top and bottom orthographic views, usually with a perspective view. Foreign filers still budget for it.

Since May 2019 that has not been the rule. The JPO no longer strictly requires six views, and a single view can be sufficient where it suitably identifies the design. Views that do not contribute to identifying the design may be omitted. The test moved from a fixed count to whether the set of drawings actually identifies the design being claimed.

The practical effect cuts both ways. It reduces cost on simple articles, and it removes the safety of a mechanical checklist. If a surface is not shown and its appearance is not deducible from the views filed, the design has not been identified, and the deficiency cannot be cured later by adding matter. Deciding which views to file is now a judgement call, and it is one better made before filing than in response to an office notice. Compare the US position in our guide to design patent broken lines.

Tokyo’s courts: where the drawings become evidence

Japan concentrates patent litigation in two forums. The Tokyo District Court has exclusive first-instance jurisdiction over patent and utility model infringement actions arising in eastern Japan, with the Osaka District Court taking the west. Appeals go to the Intellectual Property High Court in Tokyo, established in 2005 as a special branch of the Tokyo High Court. Because corporate headquarters cluster in Kantō, the Tokyo bench sees the larger share of the docket.

Validity runs on a separate track. A defendant can request a JPO invalidation trial (無効審判, mukō shinpan), which if successful extinguishes the right against the world, with appeal to the IP High Court. Alternatively, and more commonly as a defence, it can plead under Article 104-3 of the Patent Act that the right should be invalidated — an argument the infringement court decides itself, effective only between the parties.

Either way the drawings are read closely. Japanese courts construe claims in light of the description and the figures, so a reference numeral that appears on a sheet but nowhere in the text, or a figure inconsistent with the claim, becomes an argument for the other side. Our note on the brief description of the drawings covers the same discipline on the US side.

What Tokyo’s industries demand from their sheets

The Kantō filing base is distinctive, and each sector pushes the drawings in a different direction.

• Electronics and semiconductors — layered cross-sections where the layer order is the invention, plus block diagrams and timing charts that have to read as engineering documents, not decoration.
• Precision machinery — exploded assemblies and sectional views with consistent hatching, frequently filed as utility models where, under Article 5(2), the sheets carry the entire disclosure.
• Pharmaceuticals and life sciences — spectra, chromatograms and dose-response graphs reproduced as clean monochrome line art, since the JPO will not take a colour plot.
• Robotics — kinematic diagrams, control-flow charts and end-effector detail views, often spanning a patent filing and a related design filing for the housing.

A robotics filer in particular will often need three coordinated sets from the same disclosure: patent figures for the mechanism, a design application for the visible housing, and possibly a partial design covering one distinctive element. Those are drawn differently and to different rules, and preparing them as one exercise avoids the inconsistencies that surface later. See our overview of patent drawing views for the underlying view taxonomy.

Why a Tokyo drawing set gets sent back

Most formality problems on Japanese filings are imported from another jurisdiction’s sheets. These are the ones we see repeatedly on work arriving from US and European families.

• Colour or greyscale carried over. A figure whose meaning depends on colour coding, or a photographic micrograph, fails the JPO’s monochrome requirement for patent drawings. Redrawing as line art usually means re-encoding the information — hatching, callouts or separate figures rather than colour keys.
• A partial design filed without the statement. The sheets arrive with US broken lines and no written identification of the claimed portion or the depiction method used. The drawing on its own does not establish the claim.
• A view set chosen by habit. Six views filed reflexively where fewer would do adds cost; conversely, dropping views without asking whether the remaining set still identifies the design risks a disclosure that cannot be cured by amendment.
• Utility model drawings treated as optional. Article 5(2) makes them compulsory, and because there is no substantive examination there is no opportunity to fix a thin set later.
• Reference numerals that drift. Numerals on the sheets that do not match the Japanese description — often a translation artefact — give a defendant something to argue about in the Tokyo District Court years later.

None of these are difficult to prevent. They are simply easier to catch before filing than after a notice of reasons for refusal has been issued and an associate is billing to respond to it.

How PerspireIP prepares patent drawing Tokyo filings

We work from whatever you have — CAD exports, engineering drawings, photographs, a competitor’s product, or a marked-up US or European sheet — and produce filing-ready figures for the JPO alongside matching sets for the USPTO, EPO and PCT where the family runs in parallel.

For a patent drawing Tokyo engagement that means monochrome line work at JIS A4, consistent reference numerals checked against the Japanese description, and view sets chosen for what the JPO now actually requires rather than for a legacy six-view habit. For design and partial-design work we mark the claimed portion by the method you specify and draft the accompanying statement so the sheets and the text agree.

Every set is checked against the formal requirements before delivery, and we correct without charge if the JPO raises a formality objection on our work. Files arrive in the formats your Japanese associate needs for electronic filing, so nothing is re-drawn at the Tokyo end. Use the order form on this page to send a brief, or see the full patent drawing service.
