Patent Drawing in Cambridge.

Cambridge files more patents per head than almost anywhere in Britain, and almost none of them are examined in Cambridge. Every patent drawing Cambridge inventors commission is bound for the Intellectual Property Office (UKIPO) in Newport, South Wales, examined under the Patents Rules 2007, and eventually read – if it is ever litigated – in the Rolls Building in London. Three cities, three audiences, one set of sheets. Add the European and PCT routes that Silicon Fen companies use as a matter of course, and the drawings have to satisfy four rulebooks that disagree with each other on one particularly awkward point: colour.

Where a patent drawing Cambridge applicant files actually goes

There is no patent office in Cambridge. The Intellectual Property Office – the operating name of the Patent Office – is headquartered at Concept House in Newport, South Wales, and that is where a UK national application is filed and examined. The practical distance matters less than it once did, since filing is electronic, but it does mean that no Cambridge applicant has an examiner they can walk in and see.

What makes the Cambridge position distinctive is that the UK national route is usually only one of three the same invention will travel. A typical Silicon Fen filing programme runs a UK priority application at the UKIPO, a PCT application twelve months later, and a European application prosecuted at the EPO – with the UK designation of that European patent taking effect nationally, because the United Kingdom remains a party to the European Patent Convention.

One point is worth stating plainly, because it is the question Cambridge clients ask most often. The UK is not part of the Unified Patent Court. The UK signed the UPC Agreement but withdrew its ratification in July 2020, so a European patent taking effect in the UK is enforced in the UK courts under UK law – not before the UPC, and not subject to a unitary patent. Membership of the EPC and membership of the UPC are separate things, and conflating them produces badly wrong advice about where a Cambridge company can be sued.

For the drawings, the consequence is straightforward: the same figures will be assessed by a UKIPO formalities examiner, an EPO formalities officer and the International Bureau, and only one of those three will refuse colour outright.

Schedule 2 of the Patents Rules 2007: the sheet-level standard

UK formal requirements are set by rule 14 of the Patents Rules 2007, which brings in Schedule 2. Schedule 2 is where the sheet-level detail lives, and it is considerably shorter than 37 CFR 1.84 – which misleads applicants into thinking it is more forgiving. It is not; it is simply less explicit, and the UKIPO’s Manual of Patent Practice fills the gaps.

• Paper — A4 matt white throughout, drawings included
• Margins — a minimum of 20mm at the top, 20mm at the left, 15mm at the right and 10mm at the bottom, and those margins must be completely blank — not even a case reference
• No frames — lines surrounding the drawing matter are not permitted
• Reproduction — every sheet must stay legible when reduced by linear reduction to two-thirds of its original size
• Lines — black, with shading allowed so long as it does not obscure detail, and hatching for cross-sections
• Lettering — capital letters and reference signs simple, clear, and more than 3mm in height
• Minimal text — and never the title of the invention or the name of the applicant or agent

The numbering rules follow the same two-register logic as every other office: the sheets are numbered consecutively in a single series, and the drawings themselves are numbered consecutively in a single series, independently of the sheets. A four-sheet application carrying nine figures is entirely normal. We set out the underlying rules across all three offices in our guide to patent drawing figure numbering.

The 3mm lettering minimum is the requirement most often missed on a patent drawing Cambridge engineers have exported straight from CAD. Default CAD annotation heights, scaled to fit an A4 sheet, routinely land under it.

The colour problem, and why it bites Cambridge hardest

This is the single most consequential divergence for a Cambridge filing programme, and it opened up very recently.

The EPO began accepting colour and greyscale drawings on 1 October 2025, under a Decision of the President of 7 July 2025 (OJ EPO 2025, A49) with a Notice at OJ EPO 2025, A57. Drawings may now be executed in colour or greyscale in durable, uniformly thick, well-defined lines, strokes or areas, sufficiently rich in contrast, and clearly displayable at 300 dpi. The concession applies only to electronic filings – via Online Filing 2.0, ePCT, MyEPO and the contingency upload service – and not to paper filing.

The UKIPO has not followed. Under current UK practice, colour drawings and colour photographs are not allowable. A specification may include photographs provided they are clear enough for reproduction, but they must be monochrome.

Nor does the PCT international phase help. Colour is not admissible under the PCT internationally: the International Bureau renders colour drawings in black and white for international publication, retaining the original on PATENTSCOPE. So a Cambridge applicant filing the same invention three ways now faces one office that welcomes colour, one that converts it, and one that refuses it.

That asymmetry lands on Cambridge harder than on most cities because of what Cambridge files. Fluorescence micrographs, immunohistochemistry panels, heat maps, flow-cytometry plots and multi-trace assay graphs are inherently colour-coded, and they are the daily currency of the Biomedical Campus and Babraham. A figure whose meaning is carried by colour does not survive conversion to greyscale – two channels that were red and green become two indistinguishable greys, and the figure stops supporting the disclosure it was filed to support.

The answer is to design the figure so colour is redundant rather than load-bearing: distinct hatching, line styles, shapes and labelled arrows doing the work that colour was doing, so the same artwork reads correctly in colour at the EPO and in monochrome at the UKIPO. Our note on the EPO colour drawing reform covers the European side in detail.

What Silicon Fen actually files, and what those figures demand

Cambridge’s filing profile is unusually concentrated. The cluster grew out of the University and its colleges – Trinity College founded the Cambridge Science Park in 1970, the first science park in the UK – and it now spans four campuses that each generate a different kind of drawing.

• Semiconductors and processor IP — Arm anchors a deep cluster of chip design and EDA work. The figures are block diagrams, pipeline and state diagrams, bus architectures and layer cross-sections. The recurring formal problem is text: a block diagram that explains itself in words breaches the minimal-text requirement and has to be rebuilt around reference numerals.
• Life sciences and drug discovery — the Cambridge Biomedical Campus, home to AstraZeneca’s global R&D centre, alongside the Babraham Research Campus and Granta Park. Expect micrographs, assay traces, dose-response curves and sequence figures — the colour-dependent set described above.
• Medical devices and surgical robotics — a strong local specialism, and the most drawing-intensive category we handle here: exploded assemblies, sectional views through instrument shafts, kinematic diagrams and multi-position figures showing an articulated end effector through its range.
• Quantum computing, photonics and sensing — optical bench layouts, cryostat schematics and control-electronics diagrams, where the figure has to distinguish optical paths from electrical ones without relying on colour to do it.
• Software, AI and cybersecurity — flowcharts and system architecture diagrams, subject to the same numeral discipline as the semiconductor work, and to the UK’s exclusions on computer programs as such.

Two categories deserve a specific warning. Flowcharts are where reference-numeral discipline collapses most often, because the boxes are self-explanatory to the engineer who drew them and opaque to a formalities examiner. And micrographs should be filed as photographs only where the subject genuinely cannot be rendered as a line drawing – a photograph is a fallback, not a shortcut around commissioning a proper figure.

A large share of Cambridge filings also originate in university spin-outs, where the technology transfer office and the founders share the file. Those cases benefit most from figures drawn once to the strictest of the applicable standards, because the same sheets will be shown to investors, to a licensee and to three patent offices.

Where Cambridge patents are litigated: the Rolls Building, not Cambridge

Drawings are drafted for an examiner and eventually read by a judge. For a Cambridge patentee, that judge sits in London.

UK patent disputes are heard in the Patents Court, part of the Chancery Division within the Business and Property Courts, or in the Intellectual Property Enterprise Court (IPEC). The choice between them is largely a question of value and complexity. IPEC is the smaller-claims forum and its limits are hard numbers worth knowing before a dispute starts: damages are capped at £500,000 on the multi-track unless the parties agree to waive the cap, and recoverable costs are capped at £60,000 for a final determination of liability and £30,000 on quantum. The Patents Court applies no cap on either damages or recoverable costs.

For a Cambridge spin-out, that structure is genuinely strategic. IPEC exists precisely so that a company without a nine-figure balance sheet can enforce a patent against a larger competitor without the costs exposure of the Patents Court – and the streamlined IPEC procedure puts a premium on a clear documentary record, because there is far less opportunity for expert evidence to rescue an ambiguous one.

The UKIPO also offers a non-binding opinions service on validity and infringement, and hears certain disputes itself – a cheaper first look that is often the right opening move for a Cambridge business weighing whether a dispute is worth taking to London at all.

All of which is an argument for consistency across the family. An infringement action will place the UK file, the European file and the PCT publication in front of the same judge. Divergent reference numerals between them is an open invitation to argue that the documents describe different things. We keep numbering identical across every member of a family, which is also the discipline behind our patent invalidation work in Cambridge.

UK registered designs are a separate filing with different drawings

Cambridge hardware companies protecting the look of a product file a registered design at the UKIPO under the Registered Designs Act 1949, and the drawing brief is not the patent brief.

A utility figure exists to explain how something works: sections, hidden detail, hatching, numerals tying elements to the claims. A design representation exists to define appearance, and the representation itself constitutes the protected subject matter. What you leave out is as consequential as what you include, because disclaimed matter narrows or broadens the scope of what is registered.

Brexit added a wrinkle Cambridge exporters should not overlook. Registered Community Designs stopped covering the UK on 1 January 2021; holders received equivalent re-registered UK designs automatically, but any new filing now needs both a UK registered design and an EU registered design to cover the same territory the single EU right once did.

US practitioners have a useful comparator in 37 CFR 1.152, which requires a design to be represented by drawings complying with 37 CFR 1.84 and containing enough views for a complete disclosure of the appearance, permits broken lines for visible environmental structure but not for hidden planes, and forbids solid black surface shading except to represent the colour black or colour contrast. UK practice is not governed by those rules, but the draughting logic transfers, and a set built to that discipline leaves an unambiguous record of what is claimed.

How PerspireIP prepares a patent drawing Cambridge filers can rely on

We work from whatever exists – CAD geometry, a confocal image stack, a supplier’s assembly drawing, a whiteboard photograph – and produce a formal sheet set built to the standard that will actually be applied to it.

• Drawn to the strictest applicable rulebook so one set serves the UKIPO, the EPO and the PCT without redrawing at each stage
• Colour-independent figure design — hatching, line styles and labelling carry the meaning, so the artwork survives the UKIPO’s monochrome requirement and the International Bureau’s greyscale conversion while still filing in colour at the EPO
• Schedule 2 compliance checks — A4, blank 20/20/15/10mm margins, no frames, lettering above 3mm, legible at two-thirds reduction
• Numeral audit against the claims and description before delivery: every claimed element numbered, no numeral used twice, no orphans in either document
• Separate design representations where appearance is being protected, drawn to define the claimed appearance rather than explain the mechanism
• Family consistency so the UK sheets match the European, PCT and US counterparts numeral for numeral

Turnaround on a standard utility set is measured in days, not weeks, and we quote on figure count and complexity rather than an hourly estimate. If a set has to be ready for a twelve-month Paris Convention deadline or a thirty-month national phase date, tell us the date and we will work back from it. We do the same work in London, and across the rest of our UK practice.
