A patent drawing Cork applicant files will be judged against Rule 12 of the Irish Patents Rules 1992 — a provision drafted from the PCT template in the early 1990s and never amended to follow the EPO into colour. That matters more in Cork than almost anywhere else in Ireland, because the county’s filing profile is dominated by pharmaceutical process and formulation work, speciality chemicals and medical devices, where a figure set is often the difference between a disclosure an examiner can follow and one they cannot. Cork filers also face a route question Dublin counsel answer daily: Ireland has closed its PCT national phase, so the sheets you prepare depend on whether you are filing nationally, taking a short-term patent, or letting a European patent take effect.

Which rules govern a patent drawing Cork applicant files at the IPOI

Irish substantive patent law is in the Patents Act 1992. The formal requirements that decide whether your sheets are accepted sit somewhere much narrower: Rule 12 of the Patents Rules 1992, as amended, with the margin figures coming through the Patent (Amendment) Rules 2009. There is no Irish equivalent of the MPEP and no office-level drawing manual. Rule 12 is the whole code.

Rule 12(1) caps the usable surface of a sheet at 26.2 cm × 17 cm, bars frames around the usable or used surface, and sets minimum margins of 2.5 cm top, 2.5 cm left, 1.5 cm right and 1.0 cm bottom. Those are the same four margins as 37 CFR 1.84(g), so the sheet geometry of a compliant US set carries over without re-layout.

• Black lines only — Rule 12(2)(a) requires “durable, black … lines and strokes without colourings”, with no colour exception and no petition route
• Legible at two-thirds — Rule 12(2)(c) tests the sheet against a photographic reduction to two-thirds of linear size
• Reference signs reconciled both ways — Rule 12(2)(i) bars signs on a figure that are absent from the description and claims, and vice versa
• No brackets, circles or inverted commas around numerals, under Rule 12(2)(d) — circled callouts are a common CAD default and are prohibited
• Lettering at least 0.32 cm high (Rule 12(2)(g)), matching 37 CFR 1.84(p)(3)
• Hatching that does not impede the reading of reference signs or leading lines (Rule 12(2)(b))
• Almost no text on the sheet — Rule 12(2)(j) permits single indispensable words, plus “a few short catch words” for electric circuits, block schematics and flow sheets

The colour rule is the one that now catches well-run portfolios, and it is a recent divergence. Rule 46 EPC, which used to carry the EPO’s drawing form requirements, was deleted with effect from 1 February 2023, and since 1 October 2025 the EPO has accepted electronically filed colour and greyscale drawings under a Decision of the President (OJ EPO 2025, A49). Irish national practice did not move with it. A colour figure set that is now entirely proper at the EPO is not filable as-is at the IPOI.

The Cork industries that actually drive local filings

Cork is not a general-purpose filing centre. Its patent output is concentrated in a handful of sectors, and each fails formalities in a characteristic way.

• Pharmaceutical manufacturing. Ringaskiddy has one of the highest concentrations of pharmaceutical employment anywhere, with Pfizer, GSK, Janssen and Novartis among the manufacturers in the harbour area, and BioMarin also in the Cork cluster. The filings are process and formulation cases, where the drawings are reaction schemes and plant flow diagrams rather than product views.
• Active pharmaceutical ingredients and speciality chemicals. Janssen’s Little Island site has manufactured bulk APIs since 1981. These cases live on flow sheets — and Rule 12(3) confirms that “flow sheets and diagrams are considered as drawings”, so they sit inside Rule 12 rather than outside it.
• Biologics and fill-finish. AbbVie manufactures at Carrigtwohill and Gilead has expanded its Cork site. Equipment, containment and single-use assembly inventions are mechanical drawings subject to the full Rule 12 line-weight discipline.
• Medtech. Device work across east Cork generates sectional and exploded views, which is where Rule 12(2)(b) hatching and Rule 12(2)(c) line weight most often collide.

For the pharma and chemicals majority, the practical risk is specific. A process flow diagram exported from engineering software arrives full of equipment tags, stream labels and unit captions. Under Rule 12(2)(j) that text is a defect unless each item is genuinely indispensable, and the permitted allowance for a flow sheet is “a few short catch words” — not labelled boxes containing sentences. We compress the labels to catch words and move the substance into numbered reference signs keyed to the description, which removes a whole category of objection.

Structural formulae are the other Cork-specific point. Irish practice normally keeps chemical formulae inside the description rather than on a drawing sheet, so a formulation case may legitimately need very few figures — and the IPOI is explicit that drawings are not obligatory at all. The judgement call is where a figure earns its place, not how many you can file.

Why a Cork patent dispute is heard in Dublin

There is no patent venue in Cork. Irish patent proceedings are brought in the High Court sitting in Dublin, and substantial patent cases are normally managed in the Commercial Court list, which takes patents regardless of the value of the claim and case-manages them on a fast track.

Ireland signed the Unified Patent Court Agreement but has not ratified it. Ratification requires a constitutional referendum, which has not been held, so there is no Irish local or regional UPC division and no Cork or Dublin seat of the UPC. A Cork business asserting or defending a patent in Ireland is in the High Court.

That matters for the figures. On a fast-tracked Commercial Court timetable your figure set is read as evidence, by a judge and by experts, against claim language drafted years earlier. A reference sign that appears in Figure 4 but was dropped from the description during prosecution, or a sectional view whose hatching obscures the numeral on the very feature in dispute, becomes an argument about disclosure rather than a formality. Our Prior Art Litigation Search in Cork and Patent Invalidation in Cork teams work from the same sheets, which is why we build them to be read twice.

European patents in Ireland: no translation, but a different drawing standard

Ireland is an EPC contracting state, and because English is both an EPC official language and an official language of Ireland, no translation of the specification is required for a granted European patent to take effect there. For most portfolios that makes the EPC route the mainstream one, and it is genuinely cheap by European standards.

But the drawing standard changes with the route. A European patent’s sheets answer to the EPO’s own presentation requirements — now set by a Decision of the President rather than by Rule 46 EPC — while a direct Irish application answers to Rule 12. Since the EPO’s colour allowance took effect on 1 October 2025, those two standards genuinely differ, and only on the national routes does “without colourings” still bite.

The working rule for a patent drawing Cork filer is to keep a black-line master and treat any EPO colour version as the derivative. Reversing that order means re-drafting under deadline pressure the moment an Irish national, short-term or PCT copy falls due. We set out the full nine-rule analysis in our guide to patent drawings in Ireland.

The PCT route into Ireland has closed — what Cork filers do instead

This is the detail that most often appears wrongly on a docket. Ireland has closed its PCT national route. An international application cannot be taken into a direct Irish national phase at the IPOI. There is no 30-month or 31-month Irish national-phase deadline to diarise, because the phase does not exist.

The PCT therefore reaches Ireland only through the EP regional phase at the EPO, which must be engaged within 31 months of the priority date. If your Cork-originating family runs through the PCT, the figure set that matters at that point is the EPO set, and the IPOI never sees it.

Two practical consequences follow. First, if you want an Irish national right from a Cork-originated invention, file directly at the IPOI rather than planning to nationalise a PCT later — that door is shut. Second, do not let a closed route delete the Rule 12 master from your workflow: a direct Irish filing or a short-term patent can still be wanted years into a family’s life, and that is a Rule 12 filing.

Short-term patents: the 10-year Cork route foreign applicants overlook

Ireland offers a short-term patent lasting up to 10 years from filing, requested on Form No. 1 under Rule 44 of the Patents Rules. It is not a utility-model registration in the German or Polish sense, but it occupies similar ground: a faster, cheaper national right for inventions with a commercial life shorter than twenty years.

For Cork’s manufacturing base this is genuinely useful. Process improvements, containment and handling equipment, and tooling for a specific production line often have a value horizon well inside ten years, and a short-term patent gives an enforceable Irish right without the cost of a full European filing.

The drawings are prepared under the same Rule 12 — there is no relaxed standard for short-term patents. Black line work, the two-thirds reduction test, reconciled reference signs and the Rule 12(2)(j) text limit all apply exactly as they do to a full application. If you later amend, Rule 31(3) requires the request to state its reasons and to be accompanied by a copy showing the amendment in red ink, and Rule 31(4) lets the Controller demand a fresh set of drawings prepared under Rules 10, 11, 12 and 15.

What a patent drawing Cork project includes

We work from whatever you have — CAD exports, P&ID and process flow diagrams, photographs of a prototype, or a hand sketch on a whiteboard — and return filing-ready sheets for the route you are actually taking.

• A black-line master set built to Rule 12, usable without modification for a direct Irish or short-term filing
• Route-matched derivatives for the EPO, the PCT and the USPTO, generated from the same master so the family stays consistent
• One reference-sign table per family, reconciled against the description and claims in both directions as Rule 12(2)(i) requires
• Flow sheets and block diagrams rebuilt so labels fall inside the Rule 12(2)(j) “few short catch words” allowance
• Sectional and exploded views with hatching opened around numerals so Rule 12(2)(b) is satisfied at two-thirds size
• Figure numbering kept as a separate sequence from sheet numbering, per Rule 12(2)(h), with the Rule 13(4) abstract figure nominated
• Replacement sheets prepared for amendment, in the form Rule 31(3) and Rule 31(4) contemplate

Clients normally come to us either before a first Irish filing or after a formalities objection. The second is more expensive, because by then the reference signs are in the description and a renumber propagates through the text. See our full Patent Drawing services, or the companion team in Dublin.

Seven checks before a Cork filing goes out

• Every line is black, with no colour and no greyscale fill anywhere on a sheet bound for the IPOI
• The sheet prints legibly at two-thirds linear size, with reference signs still readable inside hatched regions
• No numeral appears on a figure that is missing from the description or claims, and none is discussed in the text but absent from every figure
• No brackets, circles or inverted commas around any numeral or letter, and nothing lettered below 0.32 cm
• Text on the sheet is limited to indispensable single words, or to a few short catch words on a circuit, block schematic or flow sheet
• Figures are numbered consecutively in arabic numerals as a sequence independent of the sheet numbers, and the abstract figure has been nominated
• The route is confirmed before the sheets are finalised — direct IPOI, short-term patent, or EP regional phase, because there is no Irish PCT national phase to fall back on

If any of the seven is unresolved, send us the files before filing. A correction cycle at the IPOI costs more time than getting the master right once. Regional context for the jurisdiction is on our IP services in Ireland hub, and the local analysis teams are at Patent Infringement Analysis in Cork.
